The RK Series ultra-high pressure radial piston pump features a radial arrangement structure combined with valve-type flow distribution, delivering high-pressure output, strong suction capability, and low-noise operation while effectively preventing cavitation. Precision machining paired with manual lapping processes ensures high assembly accuracy and stable operation. Customizable multi-row and multi-port configurations available.

The high-low pressure compound radial piston pump is a highly modular hydraulic core component, enabling single-pump dual-pressure and dual-flow output, which significantly simplifies hydraulic circuit design. Piston quantity (1-22) can be flexibly configured based on requirements, supporting single-row and double-row structures. Two oil inlet options available: filter mesh type and aluminum housing pipe type. Rich product specifications - outer diameter 186mm and 215mm, with standard flange mounting interface. Oil outlets available in M14/M16/M18 specifications. Compact structure and stable performance, widely used in construction machinery, machine tools, and industrial automation fields.

High-Pressure Axial Piston Pump The high-pressure axial piston pump features an axial piston design with precision-machined components for stable, smooth quantitative oil supply. It delivers excellent performance with high pressure stability, low noise operation, superior contamination resistance, and precise compound flow control. The bottom suction design ensures strong suction capacity and eliminates cavitation, making it ideal for various high-pressure hydraulic systems.

SHQ Series Premium Ultra-High Pressure Solenoid-Controlled Pump Station The SHQ Series premium solenoid-controlled pump station features an aerospace-grade aluminum alloy body for lightweight and compact design. Equipped with specialized ultra-high pressure solenoid ball valves and solenoid directional valves, it ensures stable pressure output. Offers pressure-holding capability when stopped with adjustable pressure settings. Superior heat dissipation for extended operation. The M16 x 1.5 port size can be customized to meet specific requirements.
