KX Series Hollow Hydraulic Jack The KX hollow hydraulic jack features a hollow plunger design ideal for both pushing and pulling applications. It can sustain maximum load capacity at full stroke. Special hollow bushings protect the spindle and inner walls, extending product lifespan. Premium imported sealing materials ensure superior sealing, while hard chrome-plated spindles provide excellent wear and corrosion resistance. Available in single and double-acting models. All units include NPT3/8 quick couplings and dust caps.

LL Single-Acting Hydraulic Jack The LL hydraulic jack features piston rods and cylinder inner walls with hard chrome plating for superior wear resistance and corrosion protection. The base mounting holes ensure easy installation and secure fixing. Powerful springs accelerate the spindle return speed for efficient operation. Equipped with premium imported sealing materials for enhanced sealing performance. All models include M16 x 1.5 quick couplings and dust caps for convenient connectivity. Ideal for lifting, pressing, and clamping applications in industrial environments.

Lighter and shorter collapsed height than equivalent RACH single-acting models Double-acting for rapid retraction, regardless of hose lengths or system losses Built-in safety valve prevents accidental overpressurization Hollow plunger design allows for both pull and push forces Composite bearings increase cylinder life and side load resistance Hard coat finish on all surfaces resists damage and extends cylinder life Handles included on all models Floating center tube increases seal life Steel baseplate and saddle for protection against load-induced damage Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacity CR400 coupler and dust cap included on all models All cylinders meet ASME B-30.1 standards
